Iron Oxide Red Alkyd Antirust Paint
It is made of alkyd resin, iron red pigment, filler, drier, additives and solvent.
- Overview
- Description
- Applications
- Specifications
- Construction technics
- Recommended Products
Overview
| Place of Origin: | Jiangxi |
| Brand Name: | Qianlang |
| Model Number: | C53-36 |
| Certification: | ISO900/ISO14001/ISO45001/CE |
| Minimum Order Quantity: | 500kg |
| Price: | USD1.3-1.5 |
| Packaging Details: | / |
| Delivery Time: | 30days |
Description
Excellent rust prevention
Excellent adhesion
Quick drying
Excellent workability
Applications
It is suitable for use as workshop primer in pretreatment lines in shipyards, steel structure plants, etc., and as anti-rust paint for mechanical equipment. It can be used in conjunction with traditional topcoats such as phenolic and alkyd.
Specifications
| Order | Test item | metric | |
| 1 | Color and appearance of film | Iron red, smooth paint film | |
| 2 | Viscosity (Coating-4#), S | ≥60 | |
| 3 | Fineness,μm | ≤60 | |
| 4 | Drying time, (23±2℃) h | Surface drying time | ≤2 |
| Overall drying time | ≤24 | ||
| 5 | Hardness (double pendulum) | ≥0.2 | |
| 6 | Adhesion, grade | ≤2 | |
| 7 | Flexibility ,mm | 1 | |
| 8 | Impact resistance ,cm | 50 | |
| 9 | Salt-tolerant water (3% NaCl, 48h) | No abnormalities | |
Construction technics
1. Sandblast or shot blast the steel to Sa2.5, with a surface roughness of 30-50µm.
2. For substrates with old paint (same type): Remove loose, ineffective old paint and rust, then polish to St3 using pneumatic or electric tools.
3. For welding, flame cutting, or correcting burnt areas: Polish to St3 using pneumatic or electric tools.
4. Application methods include brushing, roller coating, high-pressure airless spraying, and air spraying. Add the paint to an appropriate amount of solvent (our company's supplied solvent) and stir well to a viscosity of 40-60µS. Filter through an 80-120 mesh sieve and set aside.
5. The surface to be painted must be clean and free of oil, dust, rust, etc.
6. Before applying the second coat, the first coat must be completely dry. Leave at least 24 hours between coats, and the total dry film thickness must be at least 80µm.
7. After application, all tools used should be immediately rinsed with solvent to prevent drying.
Attention:
1. When diluting, apply in small amounts and multiple times.
2. The substrate temperature must be 3°C above the dew point, and the relative humidity must not exceed 80%. Application should not be made on rainy or snowy days.
3. Compatible with our company's various alkyd or phenolic topcoats.
4. This product is packaged in 25kg x 1 iron drum.
Storage and transportation:
The effective storage period of the product is 12 months, stored in a cool and ventilated place, storage temperature: 5-30℃. During transportation, prevent cold, sunlight exposure and rain. If the expiration date is exceeded, it can be tested according to the above technical indicators, if the technical requirements are met, it can still be used.
safe guarding:
The construction site should have good ventilation facilities, and the painter should wear glasses, gloves, masks, etc., to avoid skin contact and inhalation of paint mist. Fire is strictly prohibited at the construction site.
statement:
The construction data of this product are all accumulated from laboratory tests and practical experience, for reference only. Users can refer to the actual construction conditions for adjustment. We only guarantee the technical quality of this product, and only give guidance on the actual construction situation, we will not be responsible. We have the right to modify this manual while improving the product.
